Cov phaj yas yog ib hom khoom noj khoom haus, feem ntau yog siv los tuav zaub mov thiab dej haus. Lawv muaj cov kev siv tseem ceeb hauv qab no:
1. Siv rau kev sib sau ua ke thiab noj hmo: Cov phaj yas feem ntau yog siv rau kev sib sau ua ke, noj hmo, noj mov, thiab lwm lub sijhawm kom yooj yim tuav zaub mov thiab dej qab zib, ua rau tib neeg yooj yim nyiam zaub mov thaum txo qhov xav tau kev ntxuav tais diav.
2. Siv rau kev nqa tawm thiab khoom noj ceev: cov phaj yas kuj tseem siv tau rau hauv kev nqa tawm thiab kev pabcuam zaub mov ceev kom yooj yim rau ntim thiab nqa khoom noj. Lawv feem ntau muaj cov khoom pov tseg thiab tuaj yeem muab pov tseg tau yooj yim tom qab siv, txo cov pa phem ib puag ncig.
3. Siv rau cov menyuam yaus kev sib sau ua ke thiab cov hnub yug: cov phaj yas feem ntau tuaj nrog ntau yam xim thiab cov qauv, ua rau lawv tsim nyog rau cov menyuam yaus sib sau ua ke thiab hnub yug. Lawv yog lub teeb yuag, nqa tau yooj yim, thiab tsis yooj yim tawg, ua rau lawv nyiam cov tais diav xaiv rau menyuam yaus.
4. Siv rau kev mus pw hav zoov thiab kev ua ub ua no sab nraum zoov: cov ntawv yas kuj tseem siv tau rau kev mus pw hav zoov thiab kev ua si sab nraum zoov kom yooj yim tuav zaub mov thiab dej qab zib thiab txo qhov hnyav. Lawv feem ntau muaj cov kav ntev thiab yooj yim los ntxuav, ua rau lawv haum rau siv sab nraum zoov.
5. Siv rau cov zaub mov thiab kev nthuav qhia: Cov phaj yas kuj tseem siv tau rau cov zaub mov thiab kev nthuav qhia, uas tuaj yeem npaj cov zaub mov kom zoo thiab zoo nkauj, ua kom qab los noj mov. Lawv feem ntau muaj cov duab sib txawv thiab ntau thiab tsawg, haum rau kev nthuav tawm ntau hom zaub mov.
Zuag qhia tag nrho, cov phaj yas yog cov khoom siv ntau yam uas haum rau ntau lub sijhawm thiab lub hom phiaj. Lawv yog lub teeb yuag, ruaj, thiab yooj yim los ntxuav, thiab yog ib qho ntawm cov khoom siv feem ntau siv hauv tib neeg lub neej txhua hnub.
Technical Parameter
|
Yam khoom |
UNIT |
SZ-1300A |
||
|
INJECTION UNIT |
||||
|
SCREW DIAMETER |
mm |
35 |
40 |
45 |
|
SCREW LID RATIO |
L/D |
24 |
21 |
18.7 |
|
THEORETICAL SHOT VOLUME |
CM3 |
173 |
226 |
286 |
|
POJ NIAM (PS) |
g |
158 |
206 |
260 |
|
INJECTION Pressure |
Mpa |
235 |
180 |
142 |
|
THEORETICAL INJECTION RATE (PS) |
g/s |
110 |
143 |
181 |
|
PLASTICISING CAPACITY |
g/s |
13.8 |
19.7 |
27.1 |
|
SCREW TORQUE |
N.m |
740 |
||
|
MAX.Screw tig ceev |
r / min |
250 |
||
|
HLOOV TSHIAB |
mm |
180 |
||
|
CLAMPING UNIT |
||||
|
MAX.CLAMPING FORCE K |
KN |
1300 |
||
|
MAX.QHOV TSEEB |
mm |
400 |
||
|
SPACE BETWEEN TIE BARS |
mm |
420×420 |
||
|
Mould HOM |
mm |
160-440 |
||
|
MAX. HNUB |
mm |
840 |
||
|
EJECTOR FORCE |
KN |
31.4 |
||
|
EJECTOR STROKE |
mm |
100 |
||
|
EJECTOR QUANTITY |
5 |
|||
|
Lwm yam |
||||
|
PUMP lub cev muaj zog |
KW |
13 |
||
|
PUMP Pressure |
Mpa |
16 |
||
|
LUB HOM PHIAJ |
KW |
9.2 |
||
|
KEV KHO MOB |
4 |
|||
|
SIZE |
m |
4.7×1.25×1.85 |
||
|
NET WEIGHT |
t |
4.3 |
||
|
Roj TANK CAPACITY |
L |
360 |
||
|
INTERNATIONAL DESIGNATION |
1300-410 |
|||
